Searching the Dark with the help of WireShark

⏳ 9 min read

Table of Contents

Cybersecurity Illustration

Night settles over the city like a dark silk curtain, punctured by neon signs flickering in puddles, the hum of server racks echoing down rain-slicked alleys, circuits glowing under the skin of skyscrapers. Somewhere, in a subterranean basement, a lone figure sits before an array of screens, headphones peeling sound like static, fingers dancing on keys. This figure chases shadows. Not ghosts, but packets , ephemeral whispers of data transmitted through fibre and copper, encrypted or not, hiding in plain sight. The city breathes with data, every device a node in the web, every connection a path into the abyss. You want to search the dark. You want to see what lurks in those invisible passages. You need WireShark.

There is beauty in the chaos, horror in the unknown, but above all, there is truth. In the pulsating rhythm of packets you discover patterns, corruption, compromise. Like a blade reflected in shattered glass, every fragment holds a clue. If you are new to cyber-stealth, strap in. Tonight we dive into the dark network seas, with WireShark as our lantern, our scalpel. We pierce firewalls, dissect protocols, hunt anomalies. What follows is your field-guide to seeing the unseen, smelling the electrical ozone, understanding the murmur of data that whispers secrets.

What does “searching the dark” mean in network terms

When we say “dark”, we mean traffic that’s not obvious: suspicious IPs, unexpected protocols, unknown payloads, encrypted streams, covert channels, or communication to malicious domains. We mean misconfigured devices leaking data, attackers exfiltrating files, botnets chatting, or even innocent devices gone rogue. WireShark helps us uncloak this traffic by capturing and analysing packets at the wire-level. For beginners, this means listening to everything that passes through a network interface, applying filters, reconstructing streams, watching the signs.

Setting up WireShark for deep traffic analysis

  1. Install and capture
    - On Linux: sudo apt update && sudo apt install wireshark
    - Add your user to the wireshark group (e.g. sudo usermod -aG wireshark $USER).
    - On Windows or Mac, download from official site.

  2. Choosing the right interface
    Use ifconfig or ip a (on Linux) or familiar tools to list interfaces. If you want to capture WiFi traffic, ensure monitor-mode if supported. For wired traffic, the physical NIC suffices. Beware promiscuous mode may violate policy or privacy laws.

  3. Capture filters vs display filters
    - Capture filters limit what is written to disk (e.g. tcp port 80)
    - Display filters let you scour captures after the fact (e.g. http.request && ip.dst == 192.168.1.10)

Use capture filters to avoid huge files, display filters to home in on anomalies.

Practical filters to uncover dark patterns

Here are some display filters to try in WireShark:

Purpose Filter
Find large HTTP POSTs http.request.method == "POST" && frame.len > 1000
Detect DNS requests for known malicious TLDs dns.qry.name matches "\.(xyz|top|loan|click)$"
Look for unencrypted credentials in basic auth http.authbasic || (http && frame contains "Authorization: Basic")
Unusual SSH connections ssh && !ip.src == <trusted_ip>

Replace <trusted_ip> with your local trusted address. These filters reveal traffic that may be benign or baleful.

Reconstructing streams and inspecting payloads

Sometimes you must reassemble a session. WireShark does this automatically for many protocols (HTTP, SSL/TLS, TCP streams). For example:

If traffic is encrypted (e.g. TLS), you may need keys:

Hands-on example: spotting malware beaconing

Imagine a device infected with malware calling home every minute. We want to find repeated connections to unusual hosts.

Bash script to automate filtering

bash
#!/bin/bash
# WARNING: Only run this on networks you own or with permission

# Capture for 5 minutes
sudo tshark -i eth0 -a duration:300 -w capture_dark.pcap

# Extract all distinct hosts contacted
tshark -r capture_dark.pcap -q -z conv,tcp | awk '/<->/ {print $3}' | sort | uniq -c | sort ‒nr > hosts_contacted.txt

echo "Top contacted hosts:"
head -n 20 hosts_contacted.txt

This script captures traffic, then tallies which remote hosts communicate most with your network. If a host appears with many low-volume connections at odd intervals, it may be beaconing.

Python snippet to scan PCAP for anomalies

python
#!/usr/bin/env python3
# WARNING: Analysis only, do not send captured data outside legal bounds

from scapy.all import rdpcap, TCP, IP
from collections import defaultdict

packets = rdpcap('capture_dark.pcap')
conn_counts = defaultdict(int)

for pkt in packets:
    if pkt.haslayer(IP) and pkt.haslayer(TCP):
        key = (pkt[IP].dst, pkt[TCP].dport)
        conn_counts[key] += 1

# Print flows with many short connections
for (dst, port), count in conn_counts.items():
    if count > 50 and port not in (80, 443, 53):
        print(f"Suspicious flow: {dst}:{port} with {count} connections")

This code identifies frequent connections to unusual ports that are not common web, DNS or standard ports. Such behaviour can signal persistent surveillance, C2 channels or exfiltration paths.

Protocols to inspect, anomalies to watch

Investigate timestamps, direction of flow, size distributions. A host sending many small packets at precise intervals is suspicious, even if content seems harmless.

You may be tempted to capture everything, intrude on private traffic, break encryption. Do not. Always have explicit permission to monitor networks. Respect privacy, local laws, organisational policies. Any misuse of WireShark or related tools may be illegal or unethical. Code snippets above are for educational or authorised-testing purposes only, never for illicit data collection.

Searching the Dark with the Help of Wireshark: A Practical Guide

Aim

This guide teaches you how to use Wireshark to search network traffic for evidence of activity on the darknet, such as Tor connections or traffic to unallocated IP spaces, and to interpret what you find.

Learning outcomes

By following this guide you will be able to:
- capture live network traffic and recognise darknet-related protocols or destinations
- apply and use Wireshark filters to isolate suspect traffic such as Tor or darknet port scans
- use command-line tools (tshark) to extract certificates or metadata linked to encrypted dark-web connections
- differentiate between benign encrypted traffic and traffic patterns indicating darknet usage

Prerequisites

Step-by-step practical tasks

1. Capture network traffic

  tshark -i eth0 -w darknet_capture.pcapng

2. Identify Tor protocol or darknet connections

3. Use tshark to extract certificate metadata

bash
  tshark -r darknet_capture.pcapng \
         -T fields \
         -R "ssl.handshake.certificate" \
         -e x509af.utcTime \
         -e x509s.at.printableString

4. Differentiate traffic patterns

  tcp and (frame.len > 200 or frame.len < 80)

to isolate unusually large or small packets.

5. Inspect destination IPs and darknet space

  ip.dst == 192.0.2.0/24 or ip.dst == 203.0.113.0/24

or similar reserved ranges.
- Investigate: persistent traffic to such addresses often points to scanning or reconnaissance.

6. Tag and report suspicious findings

Practical code snippets

bash
# Capture live data and save for later analysis
sudo tshark -i wlan0 -f "port 9001 or port 9002" -w tor_ports.pcapng

# Filter a pcap file for TLS traffic where certificate names are non-standard
tshark -r tor_ports.pcapng \
       -T fields \
       -Y "tls.handshake.type == 11" \
       -e tls.handshake.extensions_server_name

Use this guide to explore, detect and understand the darker fringes of network traffic. Skills developed here are immediately applicable in security monitoring, forensic analysis and network defence.

You click “Start” in WireShark, hear the static, see the first packets flow. Every fragment is a clue, every connection a suspect, every byte might scream your name. In the dim glow you uncover hidden narratives: botnets whispering commands, devices leaking secrets, malware reaching for its master. Searching the dark is not passive , it is a hunt, an interrogation of silence. Listen closely, trust your filters, sharpen your instincts and let the network stories emerge.
